As the professional manufacture, we would like to provide you 1000w Inverter with ATS Function. Hot sale market of KOSUN pure sine wave 1000w inverter with ATS (auto-transfer by pass) function with double-layer PCB board which design with the latest technical principle,inverter with ATS (auto transfer) function makes the application regular work if the gird power cut off suddenly and the inverter start to load application immediately within 16ms which keep your application interruption operation,KOSUN dc to ac single phase inverter & converter could meet the off grid power system of daily life,the reasonable price and high quality inverters provide with multi protections.
You can rest assured to buy 1000w Inverter with ATS Function from our factory. KOSUN portable pure sine wave power inverter 1000w with ATS function,it designs with the by pass function, the inverter auto switch to battery power when the city power cut off,this confirm the application working interruption.KOSUN factory could provide customers with good quality inverters with multi advantages for OEM/ODM:continue power 1000w and surge power 2000w,Soft start function,USB 5V/2.1A,auto-transfer with about 16ms for uninterrupted operation,the deep impression character,aluminium case for durability and cooling. KOSUN 1000w pure sine wave inverter with ATS function match with different types of sockets and plugs:USA/Australia/Universal/UK/France/Germany/Brazil/South Africa which could meet the global market.
Product parameter(Specification) of the 1000w pure sine wave inverter with ATS function
|
Pure Sine Wave Inverter With ATS Function |
|||||||
|
★★★★★ Highly recommended products |
|||||||
|
|
■ Pure sine wave output(THD<3%); |
||||||
|
MODEL |
|
RST1000P-112 |
RST1000P-124 |
RST1000P-148 |
RST1000P-212 |
RST1000P-224 |
RST1000P-248 |
|
OUTPUT |
RATED POWER |
1000W |
|||||
|
SURGE POWER |
2000W |
||||||
|
AC VOLTAGE |
Factory setting set at 100V/110V/120V AC |
Factory setting set at 220V/230V/240V AC |
|||||
|
FREQUENCY |
50Hz/60Hz optional |
||||||
|
WAVE FORM |
Ture sine wave(THD<3%) at rated input voltage |
||||||
|
AC REGULATION |
±10% |
||||||
|
STANDARD RECEPTACLES |
Schuko/UK/Australia/Universal/USA/France/JP/Brazile |
||||||
|
FRONT PANEL INDICATOR |
Operation and fault status |
||||||
|
INPUT |
BAT.VOLTAGE |
12V |
24V |
48V |
12v |
24V |
48V |
|
VOLTAGE RANGE |
9.8-16.2VDC |
19.7-32.3VDC |
39.5-63.5VDC |
9.8-16.2VDC |
19.7-32.3VDC |
39.5-63.5VDC |
|
|
DC CURRENT |
100A |
50A |
25A |
100A |
50A |
25A |
|
|
NO LOAD CURRENT DRAW |
<0.6A |
<0.48A |
<0.39A |
<0.6A |
<0.48A |
<0.39A |
|
|
EFFICIENCY |
89% |
>90% |
92% |
88% |
90% |
91%% |
|
|
BATTERY TYPES |
Recommend use Open & sealed lead acid battery |
||||||
|
BATTERY INPUT PROTECTION |
BAT.LOW ALARM |
10.5±0.2V |
21±0.3V |
42±0.5V |
10.5±0.2V |
21±0.3V |
42±0.5V |
|
BAT.LOW SHUTDOWN |
10.2±0.2V |
20±0.3V |
40±0.5V |
10.2±0.2V |
20±0.3V |
40±0.5V |
|
|
BAT.OVER SHUTDOWN |
16±0.2V |
32±0.3V |
64±0.5V |
16±0.2V |
32±0.3V |
64±0.5V |
|
|
REVERSE POLARITY |
yes |
||||||
|
by pass |
ATS transfer |
The power switch to battery within 2s if the city power cut off. |
|||||
|
OUTPUT PROTECTION |
OVER TEMPERATURE |
≥45ºC or ≥60% rated power, cooling fan open;≥70ºC,Shut off. |
|||||
|
Protection type : Shut down o/p voltage, re-power on to recover; by internal Thermistor detect on heatsink of power transistor |
|||||||
|
OUTPUT SHORT |
Protection type:Shut down o/p voltage;re-power on to recover |
||||||
|
OVER LOAD |
100%-120% rated load for 10 sec. |
||||||
|
Protection type : Shut down o/p voltage, re-power on to recover; by internal Thermistor detect on heatsink of power transistor |
|||||||
|
ENVIRONMENT |
WORKING TEMP. |
-15℃～+40℃@100% load;60℃ @50% load |
|||||
|
WORKING HUMIDITY |
20%90% RH non-condensing |
||||||
|
STORAGE TEMP. |
-30℃～+70℃/-22℉～+158℉ |
||||||
|
STORAGE HUMIDITY |
10%95% RH non-condensing |
||||||
|
SAFETY |
CE |
Compliance to EN55032 |
|||||
|
LVD |
Compliance to EN60950-1 |
||||||
|
ROHS |
Compliance to EN50581 |
||||||
|
E-MARK |
E13 |
||||||
|
OTHERS |
ISO9001/IATF16949/BSCI |
||||||
|
UL test |
Test report No.C 8 1 1 5 2072 ; UL order No.1 3 5 8 2 0 0 7 |
||||||
|
REACH |
No.:1907/2006 |
||||||
|
certificate of registration |
IATF 16949:2016 |
111458/A/0001/SM/En |
|||||
|
OTHERS |
USB port |
5V/2.1A |
|||||
|
DIMENSION L*W*H (mm) |
350*150*70 |
||||||
|
PACKING(cm) |
48*42*30 ;4pcs/CTN,15.8KG |
||||||
Product feature and application of the 1000w pure sine wave inverter with ATS function
①. Fuse：built-in
②. 1.5 times rated power for 10s,2 times for 2s(inverter)
③. USB:5V/2.1A
④. Plastic terminal TP-56 for more safety operation
⑤. Protection:LED indicator & Audible alarm
⑥. Input voltage range:‐15%~+25%
⑦. Output voltage regulation:±10%
⑧. auto-transfer switch by pass function
⑨. .protections:Over temperature/over load/short circuit/reverse polarity protection/earth leakage;
⑩. Applications:electrical applications like TV/microwave/washing-machine /air-conditioner /hair dryer /oven;electrical vehicles,truck,yacht,outside portable power source for lighting,charging etc.
Product Qualification of the 1000w pure sine wave inverter with ATS Function
A. CE Compliance to EN55032
B. RoHS Compliance to EN50581
C. LVD Compliance to EN60950-1
D. E-Mark E13
E. IATF 16969
F. REACH/UL/TUV report
Deliver,Shipping And Serving of the 1000w pure sine wave inverter with ATS function
It is a flexible transportation for the power inverter to clients such as express/train/ocean/air etc which could meet different customers choice.The factory manage the materials in advance after confirming the order,and then,produce the cargoes which save more time for the whole process.1000w pure sine wave inverter with ATS function pack with customized color box or neutral packages according to the customer demands.
FAQ
A. What character of your company?
KOSUN are one of professional manufacture with two factories built in 2011 which equip with advanced auto-machine and modern assembly line for the standard process of produce,the products are more stable for the long time operation.The main products include pure sine wave inverter,inverter with charger,modified sine wave inverter,battery charger and power station etc,thus,welcome to negotiate with us for more information you want.
B. Do you accept OEM produce?
Yes,of course. We would like to provide you the OEM,ODM produce for popular market which will improve the market share on your region.
C. Whether you accept small order?
Yes,small trial order is welcomed,contact with us for more information you want,we are glad to offer you satisfied service;
D. How about the warranty?
Warranty is 18 months for all goods.
