Reasonable price 24V 10A battery charger supply by the professional factory which built over 10 years and the smart charger is engineered with matured technology.Please select the switch to position S and select dip switch No.1-5 to get the optimum charge to suit your battery specification.
Stable 24V 10A battery charger design with 2 layers PCB board for more higher efficiency operation.Please connect the AC input cable to the utility which match the various types plug:USA/Australia/Universal/Europe/UK/France/Germany/Italy/South Africa for the different market demand.The correct method for the operation smart battery charger: Turn on the power switch after connected the battery to the DC output,the “Power on” LED lights up,it indicates the device ready for charging.The bulk LED light on means the battery charger beginning at the first stage of charging;the “ABS” LED light on,the charger is delivering constant voltage to the battery with reduced current;the “Float” LED on,the charging current is decreased and the charging voltage is held at a constant level,now the battery is under float constant charging.
Product parameter(Specification) of the 24V 10A battery charger
|
New Series Battery Charger |
||||||||||||
|
★★★★★ Highly recommended products |
||||||||||||
|
|
■ LED indicator light show charging states; |
|||||||||||
|
SPECIFICATION |
||||||||||||
|
MODEL |
GS1210B |
GS1220B |
GS1230B |
GS1240B |
GS1280 |
GS2410B |
GS2420B |
GS2440B |
GS4805B |
GS4810B |
GS4820B |
GS3625B |
|
Input voltage |
AC 110V(90-120V)/AC 220V(189V-240V) |
|||||||||||
|
Output voltage |
DC 12V |
DC 24V |
DC 48V |
DC 36V |
||||||||
|
Max charing current |
10A |
20A |
30A |
40A |
80A |
10A |
20A |
40A |
5A |
10A |
20A |
25A |
|
Output frequency |
47~63HZ |
|||||||||||
|
Charging way |
Automatic 3 stage charging |
|||||||||||
|
Stage 1:bulk charge; Stage 2:absorption charge; Stage 3:float charge |
||||||||||||
|
Float charge voltage |
13.8V |
27.6V |
|
55.2V |
41.4 |
|||||||
|
Absorption charge voltage |
14.2V(G); 14.4V(S); 14.6V(F/Li) |
28.4V(G); 28.8V(S); 29.2V(F/Li) |
|
56.8V(G); 57.6V(S); 58.4V(F/Li) |
42.6V(G);43.2V(S); |
|||||||
|
Efficiency |
>85% |
|||||||||||
|
Protection function |
Reverse polarity;output short circuit;over temperature;over voltage;over load;over current |
|||||||||||
|
LED indicator |
5 LED indicators for different charge status |
|||||||||||
|
Product dimension(CM) |
13*15*5 |
16*15*7 |
26*15*7 |
26*15*7 |
25*22*7.5 |
16*15*5 |
26*15*7 |
25*22*7.5 |
16*15*7 |
26*15*7 |
25*22*7.5 |
25*22*7.5 |
|
Product net weight |
0.75KG |
0.85KG |
2.1KG |
2.2KG |
3.9KG |
2.1KG |
2.2KG |
3.64KG |
0.85KG |
2.2KG |
3.58KG |
3.9KG |
|
Certification |
CE-EMC/LVD,RoHS |
|||||||||||
|
Case color |
Optional(black/orange/yello/green/gray/red ect.),factory default color is blue |
|||||||||||
|
Packing |
Poly bag+EPE+inner box+carton 1pc/inner box |
|||||||||||
|
12PCS/CTN |
5PCS/CTN |
6PCS/CTN |
6PCS/CTN |
2PCS/CTN |
2PCS/CTN |
6PCS/CTN |
2PCS/CTN |
5PCS/CTN |
6PCS/CTN |
2PCS/CTN |
2PCS/CTN |
|
|
Replaceable fuse+instruction book+connection wire |
||||||||||||
|
CTN dimension(CM) |
54*42*30 |
32*45*38 |
42*42*46 |
42*42*46 |
43*31*36 |
32*45*38 |
42*42*46 |
43*31*36 |
32*45*38 |
42*42*46 |
43*30*36 |
43*31*36 |
|
N.W./G.W./CTN(KG) |
16.5/17.5 |
4.5/6.5 |
12.6/17.3 |
13.2/17.9 |
8.7/9.7 |
7.0/10.5 |
13.2/17.9 |
8.52/9.21 |
4.5/6.5 |
13.2/16.39 |
8.61/9.21 |
8.52/9.11 |
Product feature and application of the 24V 10A battery charger
①. LED indicator light show charging status.
②. Temperature controlled cooling fan;
③. 3-stage battery charging:bulk charge,absorption charge,float charge
④. Reverse polarity protection:connect to battery,no harm;not connect to battery,no output.
⑤. Short circuit protection
⑥. Over temperature protection
⑦. Battery type selector
